รายละเอียดสินค้า :

• Accepts thermocouples J, K, N, R, T, S, B, E,  Pt100 RTD, 0-20 mA, 4-20 mA, 50 mV, 0-5 Vdc and 0-10 Vdc

• Internal resolution: 32,767 levels (15 bits)

• Displayed resolution: 12,000 levels

• Dual LED display: red upper display for PV, 10 mm high; green lower display for SV,  8 mm high

• Sampling: up to 55 measurements/second

• Control output update: up to 20 ms

• Isolated 4-20 mA output with up to 32,000 resolution levels (15 bits), 550 ohms maximum load

• 2 SPST relays 1,5 A / 240 Vac/dc and 1 SPDT relay (optional)

• 3 A/250 Vac/dc

• Power supply: 100 to 240 Vac/dc, 50/60 Hz; optional 24 Vac/dc

• Maximum consumption: 9 VA

• Operating environment: 5 to 50 °C, 30 to 80% RH

• Protection:

• NEMA 4 front bezel (IP65), PC UL94 V-2

• Case IP20, ABS + PC UL94 V-0

• Rated CE and UL.

• Dimensions: 48 x 48 x 110 mm, 1/16 DIN

• Panel cutout: 45.5 x  45.5 mm (1.79 x 1.79 in

• Approximate weight: 150 g (5.29 oz.)
